Tower Crane Lifting Cylinder

Tower Crane Lifting Cylinder is a heavy-duty hydraulic actuator specifically designed for construction machinery and tower crane systems. It is primarily used to control the lifting, lowering and precise positioning of heavy loads, ensuring safe and efficient operation in high-altitude construction projects.

Features:

The tower crane hydraulic cylinder engineered by Qingdao Micro Precision Machinery delivers superior performance for heavy-load handling, providing exceptional strength and reliability for construction lifting applications. As a robust lifting solution, its precision hydraulic control guarantees smooth and stable operation, while premium sealing components (such as Parker or equivalent) minimize friction and extend service life. Custom specifications including stroke length, mounting styles and pressure ratings are available to meet various project requirements.

Material：

Barrel:

- Standard: Quenched & tempered 45# steel (Hard chrome-plated, ≥0.05mm)

- High corrosion resistance: Stainless steel 304/316 (Coastal/humid environments)

Piston Rod:

- 42CrMo alloy steel (High-frequency quenching + chrome plating, HRC50-55)

- Optional ceramic coating (Anti-wear for grain abrasion)

Seal Materials:

- NBR (Standard conditions)

- FKM (High temp/chemical resistance)

- PU (High wear resistance, ideal for dusty environments)

Seal Brand：NOK, Parker, MAPKER, SKF, etc.

Maintenance Guidelines:

- Seal Replacement: Every 2 years or 500K cycles (Condition-based)

- Oil Cleanliness: NAS 1638 Class 8 or higher

- Corrosion Inspection: Biannual checks for coastal areas

Parameter:

Service

25 years of experience in hydraulic cylinder manufacturers

MPM cylinders are mainly used in:

1- Construction machinery

(Hydraulic lifting cylinders and steering cylinders for cranes/forklifts/tractors/loaders/excavators)

2- Industrial equipment

(Hydraulic cylinders/tie rod cylinders/compact cylinders)

3- Ships and offshore machinery

(Heavy cylinders, stainless steel hydraulic cylinders)

If you can provide us with the following technical parameters, we can design and customize piston hydraulic cylinders according to your needs:

1. Bore

2. Rod diameter

3. Stroke

4. Working pressure

5. Installation type

6. Push or pull back capacity
