The injection molding machine ejection hydraulic cylinder function: drives the injection platform to move.

Injection molding machine ejection hydraulic cylinder specifications:

Bore diameter 63mm～140mm

Rod diameter 36mm～90mm

Stroke≤1500mm

Thrust: Maximum 384KN

(Bore diameter 140mm/pressure 25MPa)

Injection molding machine ejection hydraulic cylinder material: cast steel ZG270-500, cast steel ZG310-5, alloy steel 18MnMoNb, 45# steel ingot forging, 42CrMn overall forging

Injection molding machine ejection hydraulic cylinder oil seal brands: Japan NOK, Parker oil seal, American MPI, Swedish SKF, Austrian polyurethane oil seal, customer-specified brands are accepted.

Advantages of injection molding machine ejection hydraulic cylinder products produced by Qingdao Micro Precision Machinery Co., Ltd.:

1. Compact structural design, use of high-strength materials and special heat treatment and welding processes ensure that the cylinder has extremely high fatigue durability life under high pressure and heavy load.

2. Low-friction sealing system design using special materials to meet customer requirements for low starting pressure, low oil film, and fast response.

The design has a wide temperature range (-25℃～+120℃), and can provide customized services for higher or lower temperature cylinders

3. Reasonable oil drain hole design can effectively solve the problem of heavy oil film caused by high frequency and fast speed, and avoid "trapped pressure" in the sealing system. At the same time, the accumulated oil can flow back to the tank through the hose, improving anti-pollution capabilities. high

4. All specifications of cylinders are designed by professional engineers

5. We use high-quality sealing kits purchased from American MPI, Japanese NOK and Swedish SKF.

6. All materials are processed by skilled workers and advanced CNC lathes

7. All hydraulic cylinders are 100% tested before leaving the factory to ensure that each cylinder meets the requirements

8. The hydraulic cylinder is packed in wooden boxes to ensure that the goods reach the customer safely.

9. The product has a one-year warranty and provides lifelong tracking service to solve any problems you encounter during use.
